SKU:ZCVRB60N

Kingsman 60" ZCVRB60 Linear Direct Vent Gas Fireplace

Name: Kingsman 60" ZCVRB60 Linear Direct Vent Gas Fireplace
Brand: Kingsman
SKU: ZCVRB60N
Price: 4417.92 USD
Availability: InStock

$4,417.92

Sale Sold out

Shipping calculated at checkout.

Fuel Type Natural Gas Liquid Propane Gas

Ignition Type Millivolt IPI

Product variants

Free Shipping on Orders Over $300
Same-Day Order Processing

OVERVIEW

The ultimate in Zero Clearance Direct Vent Fireplaces for new home construction or renovation, and your best choice for installation anywhere throughout your home. Warm up your favorite room with the beauty of a Linear Fireplace.

The Kingsman Linear Direct Vent Gas Fireplace Millivolt / IPI Pilot is a great addition to any home. This attractive linear-style fireplace comes with tempered glass, a safety barrier screen, and decorative bronze glass. it's suitable for mobile homes, bedrooms, or bed-sitting rooms.

Kingsman 66-Inch Zero Clearance Linear Direct Vent Gas Fireplace with Fire Glass offers a formidable direct vent gas fireplace option for your home. Featuring heavy-duty steel construction, this classic design offers durability to withstand the test of your time. With its premium burner system, realistic flame pattern, and impressive fire glass, this appliance replicates the design of a traditional wood fireplace while incorporating an up-to-date styling, as well. With its safe and authorized design, this unit are often installed during a bedroom, bed-sitting room, or perhaps during a manufactured home.

This fireplace are often customized in a variety of ways. Additionally, this unit are often purchased with a remote-ready millivolt ignition system or an intermittent pilot ignition (IPI). This fireplace also can be purchased with a porcelain reflective liner to further customize your appliance.

STANDARD FEATURES

Color: Black
Tempered glass
Safety screen barrier
Attractive linear style
Fuel Type: Natural Gas, Propane Gas
Includes decorative bronze glass
Mobile home, bedroom and bed sitting room approved
Product Dimensions: 66 3/16" W x 39 9/16" H x 19 3/8" D
Hi/Low Millivolt or IPI valve system will operate during power failures

*Venting Requirements: This unit requires venting pipe with an inner diameter of 5 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.

INCLUDES

Linear burner
Safety screen barrier
Bronze glass media
SIT Valve with Hi/Lo Adjustment

PRODUCT SPECIFICATION

Model	ZCVRB60N/NE	ZCVRB60LP/LPE
Fuel	Natural	Propane
Flue	Top	Top
Gas Control	Millivolt / IPI	Millivolt / IPI
Input Max.	35,000 BTU	35,000 BTU
Input Min.	23,000 BTU	28,000 BTU
FE (p.4.1-02)%	55.27% / 56.66%	55.27% / 56.66%
Flue Size	5”/8”	5”/8”
Glass Size	60" W x 17 7/8" H	60" W x 17 7/8" H
Glass Type	Tempered	Tempered
Size (WxHxD)	66 3/16” x 39 9/16” x 19 3/8”	66 3/16” x 39 9/16” x 19 3/8”
Viewing Area	61 1⁄8” x 19 15/16”	61 1⁄8” x 19 15/16”
Venting	5” Flex or 8” Hard Pipe	5” Flex or 8” Hard Pipe
Electronic Ignition	NO / YES	NO / YES
Certification	Heater	Heater
Bedroom Approved	Yes	Yes

DIMENSIONS

CA Residents: See Prop 65 WARNING

OPTIONS & ACCESSORIES

Click to see Conversion Kit

Conversion Kit

Conversion Kit to Propane Millivolt (60ZCVRB-CKLP)

For Millivolt Units only
Natural gas to propane
Complete with conversion instructions
For use with ZCVRB60 Direct Vent Zero Clearance Gas Fireplace
Includes all necessary gas valve and pilot assembly conversion components

Conversion Kit to Natural Gas Millivolt (60ZCVRB-CKNG)

For Millivolt Units only
Propane to natural gas
Complete with conversion instructions
For use with ZCVRB60 Direct Vent Zero Clearance Gas Fireplace
Includes all necessary gas valve and pilot assembly conversion components

Conversion Kit to Propane IPI (60ZCVRB-CKLPI)

For IPI Units only
Natural gas to propane
Complete with conversion instructions
For use with ZCVRB60 Direct Vent Zero Clearance Gas Fireplace
Includes all necessary gas valve and pilot assembly conversion components

Conversion Kit to Natural Gas IPI (60ZCVRB-CKNGI)

For IPI Units only
Propane to natural gas
Complete with conversion instructions
For use with ZCVRB60 Direct Vent Zero Clearance Gas Fireplace
Includes all necessary gas valve and pilot assembly conversion components

Click to see Enclosure Grill

Enclosure Grill

Enclosure Ventilation Grill Front (VL60EG)

Product Dimensions: 46 9/16" W x 2 1/2" H
Comes with screws
For use with ZCVRB60 fireplaces
3 5/8" x 60 5/8" required opening
Includes louver grill, out trim grill mount, upper and lower frame for hidden grill mounts

Enclosure Ventilation Grill Side (VL60EGS)

Product Dimensions: 15 1/4" W x 6 5/8" H
Set of two grills
For use with ZCVRB47, ZCVRB60 fireplaces
6 5/8" x 15 1/4" required opening each
Must be within 3/4" of sealed enclosure top

Click to see Surrounds Trim Kit

Surrounds Trim Kit

Stainless Steel Surround Trim Kit (ZCVRB60S1SS)

Color: Stainless Steel
Surround trim kit
1 1/2 inches wide
Attractive stainless steel finish
Specifically designed for Kingsman ZCVRB60 Fireplaces

Black Surround Trim Kit (ZCVRB60S1BL)

Color: Black
Surround trim kit
1 1/2 inches wide
Attractive black finish
Specifically designed for Kingsman ZCVRB60 Fireplaces

Click to see Liner Kit

Liner Kit

3 Piece Porcelain Reflective Liner Kit (ZCVRB60PL)

Color: Reflective Black
Amplifies the flame presentation via reflective qualities
Durable porcelain coated steel finish
Installation hardware included
Sleek modern appearance compliments fire glass installations
Designed specifically for ZCVRB60PL series fireplaces

Click to see Assorted Cannonball

Assorted Cannonball

Assorted Cannonball (RBCB1)

Color: Various Colors
Unique design alternative to glass media
Design for Kingsman fireplaces and stoves
Can be used with glass media accents

Click to see Fan Kit

Fan Kit

Speed Temperature Sensing Fan Kit (Z46FK)

Squirrel cage blower design for quiet and powerful operation
Thermal switch for automatic on/off operation
Variable speed control with built-in all off setting
Designed to fit Kingsman fireplaces

Click to see Accent Lighting

Accent Lighting

Universal Light Kit (ULK64)

Four lamps
Universal light kit
Optional accessory
For use with ZCVRB60 fireplaces

Click to see Tile Lip Kit

Tile Lip Kit

Tile Lip Kit (V60PTLK)

Three pieces
Optional accessory
Includes 11 screws
1 bottom piece, 2 side
For use with ZCVRB60 fireplaces

Click to see Thermostat

Thermostat

Wall Mount Thermostat- For Millivolt Units (Z2MT)

Simple on/off millivolt thermostat design
Easy to use digital control
Allows convenient operation of gas appliances
Simple to wire to existing millivolt systems

Programmable Digital Wall Mount Thermostat- For Millivolt Units (Z80PT)

Schedule programmable for desired operation
Works with Kingsman millivolt appliances
Easy to read digital LCD display

Click to see Remote Control

Remote Control

	On/Off Remote Control for Millivolt/IPI Units (GFRC) Simple on/off operation for millivolt appliances Allows for the operation of the appliance without manual control Included receiver easily mounts within the appliance chassis Reliable RF transmitter operation
	Thermostat Remote Control Millivolt/IPI Units (GTRC, EGTRC) On/off operation with modulating thermostat control Allows for the operation of the appliance without manual control Included receiver easily mounts within the appliance chassis Reliable RF transmitter operation
	Thermostat On/Off modulating for Natural Gas/Propane Millivolt/IPI Units (GTMRCN, GTMRCP, EGTMRCN, EGTMRCP) On/off operation with modulating thermostat control Allows for the operation of the appliance without manual control Included receiver easily mounts within the appliance chassis Reliable RF transmitter operation Includes high/low modulating motor for natural gas and propane gas fireplaces
	Thermostat On/Off modulating and fan control for Natural Gas/Propane Millivolt/IPI Units (GTFRCN, GTFRCP, EGTFRCN, EGTFRCP) On/off operation with modulating thermostat control Allows for the operation of the appliance without manual control Included receiver easily mounts within the appliance chassis Reliable RF transmitter operation Includes high/low modulating motor for natural and propane gas fireplaces Allows for control of optional fan operation

Click to see venting products

venting products

Horizontal Vent Starter Kit for 5x8-Inch Venting - Z58HSK5
	When your chimney twists and turns, the Horizontal Flex Vent Chimney Pipe Starter Kit can help the smoke navigate its way out of the house. Includes 5 ft. of flex pipe, termination, and wall thimble
45-Degree DirectVent Pro Elbow - 58DVA-E45
	Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 45°. Finish: Galvanized & Black.
90-Degree DirectVent Pro Elbow - 58DVA-E90
	Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 90°. Finish: Galvanized & Black.
5"x8" DirectVent Pro Pipe Length
	Features a fully unitized twist-lock construction in both 4” x 6 5⁄8” and 5” x 8” vent sizes. Use of sealant is optional unless specified by the appliance manufacturer. Finish: Galvanized & Black.
5"x8" DirectVent Pro Pipe Extension
	Use to add length to a straight length of DirectVent Pro. 8 ½” pipe adds 3”- 7” of length, 16” pipe adds 3”- 14 ½” of length when used with rigid sections of pipe. Direct vent lengths feature a fully unitized, twist-lock construction. Available in black or galvalume exterior.
5"x8" DirectVent Pro Adjustable Pipe
	Use of sealant is optional unless specified by the appliance manufacturer. Available in black or galvalume exterior.
DirectVent Pro Wall Strap - 58DVA-WS
	Use to support vent pipe. Provides 1” clearance. Recommend installing Wall Straps at 4-foot intervals on vertical runs.
DirectVent Pro Ceiling Firestop - 58DVA-FS
	Required for multi-story vertical installations on the second floor and any subsequent floors.
DirectVent Pro Attic Insulation Shield - 58DVA-IS
	Required for installations that pass through an attic to prevent insulation and debris from accumulating near the vent. Provides 1” clearance to combustibles.
DirectVent Pro Adjustable Roof Flashing - 58DVA-F6
	Use to weatherproof the penetration of vent pipe through the roof. Select roof flashing based on pitch of the roof. For pitches of 0/12 - 6/12. Storm Collar required. Made of galvalume.
DirectVent Pro Steep Roof Flashing - 58DVA-F12
	Use to weatherproof the penetration of vent pipe through the roof. Storm Collar required. Made of galvalume.
DirectVent Pro Dead Soft Aluminum Flashings - 58DVA-F6DS
	Available in sizes 4”x 6 5⁄8” and 5”x 8”, in 0/12-6/12 (shown) and 7/12-12/12 styles. Made of malleable dead soft aluminum. Use with metal or tile roofs.
DirectVent Pro Storm Collar - 58DVA-SC
	Use to maintain a weather tight resistant seal between the pipe and the flashing.
DirectVent Pro High-Wind Termination Cap - 58DVA-VCH
	Available in aluminum. Use for vertical terminations only. For vertical terminations only. Provides improved performance in high wind conditions.
DirectVent Pro Low-Profile Termination Cap - 58DVA-VC
	Available in aluminum and stainless steel (S). Use for vertical terminations only. Check the appliance manufacturer’s instructions to determine which caps are approved for use with their appliance.
DirectVent Pro Wall Thimble - 58DVA-WT
	Use with Square Horizontal Cap only. Provides a complete wall-pass-through and firestop. Refer to the appliance manufacturer’s installation instructions for requirements.
DirectVent Pro Square Horizontal Termination Cap - 58DVA-HC
	Use for standard and high-wind through-the-wall termination. Check installation instructions for restrictions on horizontal cap terminations. Available in aluminum, stainless steel (S), and copper (C).
5'/8'/20' Expanded Flex Kit Comes with Springs, Screws and Mill Pac
	This Flex Kit is designed to be used as a part of the Horizontal Vent Starter Kit for 5/8" Chimney Collection. The kit measures 5" by 8" in diameter and measures 5', 8' and 20' long when stretched.
5"/8" Flex Connector - ZDV5FC, ZDV8FC
	This chimney vent is equipped with a flex connector that measures five / eight inches in diameter.
5"/8" Flex Clamp - ZDV5FCL, ZDV8FCL
	This clamp is 5 / 8 inches in diameter. Although the chimney or chimney vent isn't included during this purchase, these things are available for individual sale. Strong enough to withstand pressure
4" Standoff Spring Spacer - ZDV4SS
	Spring standoff spacer is simply the part needed for your chimney vent. This spring spacer measures 4 inches in diameter and has the potential of withstanding years of use. This spacer also will keep its polishing color.
5/8" Horizontal Round Vent Termination - Z58HT
	This Round Horizontal Chimney Pipe Vent Termination provides a circle termination for your chimney.
Horizontal Wall Thimble Shield for Low Enclosures - Z58WTS
	The horizontal wall thimble is a shield for low enclosures and helps traps any unwanted particles in the air. this is often just one type of enclosures that Kingsman provides.
Universal Safety Cage for Horizontal Termination - FDVHSCU
	Universal Safety Cage. Designed for Horizontal Termination. Use with Horizontal Vent Starter Kit.
8" Roof Flashing with Storm Collar - Z58AAF, Z58AF2, Z58AF3
	The roof flashing with storm collar purchase is one of delicate workmanship combined with lasting durability. This storm collar measures 8" in inner diameter. This product has the capability of sealing the vent lengths that protrude from a sloped roof.
8" Storm Collar for Venting - ZDV8SC
	Storm Collars are useful for wetter climates as they divert water from vertical pipes to the flashing around. This Storm Collar will effortlessly snap around the vent pipe and fasten into place, providing you the peace of mind. This Kingsman Storm Collar matches the Kingsman 5"/8" vent systems.
5/8" Vertical Chimney Vent Termination - Z58VT
	It's designed for 5/8" chimney pipes. In fact, it's just one of the various parts that make up the Horizontal Vent Starter Kit Collection for 5/8" Chimneys.
24" Attic Insulation Shield - Z58AIS24
	This shield will protect your attic and roof from the heat that escapes through the chimney. The shield offers 24" of insulation designed to surround your chimney.
Vertical Chimney Vent Offset Support - ZDVVOS
	It'll support your chimney through inclement weather, including heavy rain, snow accumulation, and wind, also as natural wear from gravity over time. The support has been tested for durability and function.
Firestop Spacer for 5x8" Venting - Z58FS
	This Chimney Vent Firestop Spacer provides space between the heat of the smoke going up the chimney. This piece is designed to be used as a part of the Horizontal Vent Starter Kit for the 5/8" Chimney Collection.
Roof Support for Venting - Z58RS
	Designed to be used with 5/8" chimney. Part of the Horizontal Vent Starter Kit for 5/8" chimneys
Hard Chimney Pipe Adapter - Z58DFA
	This Hard Chimney Pipe Adapter is just one item in the Horizontal Power Vent Starter Kit for 5/8" Chimney Collection.
DirectVent Pro Vinyl Sliding Standoff - 58DVA-VSS
	Use as a heat shield on structures with vinyl siding, or other temperature-sensitive materials, to help prevent warping and or melting of the material.
DirectVent Pro Horizontal Windguard - 46DVA-WG
	Fits both 4” x 6 5⁄8” and 5” x 8” terminations. Use with through-the-wall termination cap where high winds are present. Use as a safety heat shield to prevent children or others from coming into contact with the vent termination cap.

DOWNLOADS
