SKU:IDV26N

Kingsman 33" IDV26 Direct Vent Gas Fireplace Insert

Name: Kingsman 33" IDV26 Direct Vent Gas Fireplace Insert
Brand: Kingsman
SKU: IDV26N
Price: 3148.0 USD
Availability: InStock

$3,148.00

~~$3,778.00~~ $3,148.00

Sale Sold out

Shipping calculated at checkout.

Fuel Type Natural Gas Propane

Ignition Type Millivolt (remote optional) Proflame 1 IPI (remote optional) Proflame 2 IPI with Remote

Product variants

Log Set (Required to Complete)

Glass Support Platform (Required to Complete)

Conversion Kit

Clean View Kit (Required to Complete)

Surrounds

Riser For Surrounds

Liner Kit

Mantel Clearance Shield

Log Bits Kit

Controllers

Free Shipping on Orders Over $300
Same-Day Order Processing

OVERVIEW

Convert your wood-burning fireplace to gas, for a new standard of warmth, beauty, safety and convenience.

This Kingsman IDV26 Direct Vent Insert is a great option. With an efficiency rating of 67%, variable speed blower, and dual burner, this fireplace insert could be a high-performing upgrade to any existing wood-burning fireplace. These vent inserts are often installed in any fireplace that exceeds 29.5" wide, 14.125" deep, and 19.5" tall. This insert also includes an adjustable thermostat that permits you to manage the temperature, and therefore the high BTU output allows you to supplement or replace your existing home heating system.

Inserts are complete units that fit into existing wood-burning fireplaces. They require no additions such as glass doors or screens and contains a combustion chamber with gas logs.

Uses a dual vent system, generally two 3" flex gas lines, one pipe is for exhaust, while the other pipe brings in outside air for combustion. the look of those inserts allows for a totally sealed system that doesn't compromise the within air quality of your home.

Kingsman IDV26 Clean View Direct Vent Gas Fireplace Insert with Media provides a premium gas fireplace insert for your home. This insert features heavy-duty steel construction to make sure long-term durability, while ceramic heat-radiating glass offers an impressive view of the firebox. A dual burner with glowing embers offers a realistic flame presentation, while a high-quality ignition allows for easy, safe, and effective ignition of your fire whenever. For added comfort, a heat-activated blower with variable speed control offers increased heat circulation for simpler warming capability.

This unit offers an impressive amount of customization to satisfy the requirements of your installation. choose between propane or natural gas options, add an optional liner, choose between manual or intermittent pilot ignitions and benefit from one of the quality front options to match your tastes. you'll also select from a split oak log set for a traditional appearance or a more contemporary bronze fire glass burner as your project requires.

STANDARD FEATURES

Color: Black
On/Off Rocker switch
65.3% effencicy rating
Matchless Piezo Ignition
Heat radiating ceramic glass
Dual Burner with glowing embers
Heat activated blower with variable speed control
Product Dimensions: 32 3/4" W x 21 1/4" H x 15 7/8" D
Able to be equipped with a full line of remotes and wall switches
Includes safety barrier screens to prevent accidental contact with hot glass
Able to utilize either a detailed split oak log set or contemporary glass media
Reliable standing pilot valve system ensures ready operation during power outages
Fireplace insert with dual burners, glowing embers, and variable speed blower assembly
Able to be used with gas control components pivoted in or out (must use correct surround for each configuration)
Millivolt valve system allows operation during power failure with adjustable flame control

*Venting Requirements: This unit requires venting pipe with an inner diameter of 3 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.

PRODUCT SPECIFICATION

Model	IDV26N/NE/NE2	IDV26LP/LPE/PE2
Fuel	Natural	Propane
Flue	Top	Top
Gas Control	Millivolt / IPI	Millivolt / IPI
Input Max.	30,000 BTU	30,000 BTU
Input Min.	21,000 BTU	25,000 BTU
FE (p.4.1-02)%	65.25% / 67.37%	66.30% / 68.30%
Flue Sizes	3/3"	3/3"
Glass Size	27 1/2"W x 17 1/4" H	35 5/8" W x 29 9/32"H
Glass Type	Ceramic	Ceramic
Size (WxHxD)	28"W x 19 1/2"H x 14 1/4" D	28"W x 19 1/2"H x 14 1/4" D
Viewing Area	25 1/2"W x 15 1/4"H	25 1/2"W x 15 1/4"H
Venting	3/3" Flex	3/3" Flex
Electronic Ignition	Yes	Yes
Certification	Heater	Heater
Bedroom Approved	Yes	Yes

INCLUDES

Dual Burner with Glowing Embers
Ceramic Glass
Variable Speed with Thermostat Controlled Blower
Safety Screen

CA Residents: See Prop 65 WARNING

OPTIONS & ACCESSORIES

Click to see Log Set or Glass Support Platform (Required to Complete)

Log Set

Fiber Split Oak Log Set (LOGF27)

Easy to install and service as needed
Lightweight ceramic fiber construction
Realistic look that mimics the appearance of freshly split logs
Designed specifically for IDV26 series fireplace inserts

Glass Support Platform

Glass Support Platform with Bronze Decorative Glass (RSP10)

Color: Black
Includes decorative bronze glass
Can be used with other colors of glass media
Required for glass media use in the IDV26/34/44 series fireplace inserts
Acts as both a glass platform and diffuser for a pleasing flame presentation

Click to see Conversion Kit

Conversion Kit

Conversion Kit to Propane Millivolt (26IDV-CKLP)

Gas conversion kit
Natural gas to propane
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For millivolt pilot IDV26 fireplace inserts

Conversion Kit to Natural Gas Millivolt (26IDV-CKNG)

Gas conversion kit
Propane to natural gas
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For millivolt pilot IDV26 fireplace inserts

Conversion Kit to Propane Proflame 1 (26IDV-CKLPI)

Gas conversion kit
Natural gas to propane
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For IPI Proflame 1 pilot IDV26 fireplace inserts

Conversion Kit to Natural Gas Proflame 1 (26IDV-CKNGI)

Gas conversion kit
Propane to natural gas
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For IPI Proflame 1 pilot IDV26 fireplace inserts

Conversion Kit to Propane Proflame 2 (26IDV-CKLP2)

Gas conversion kit
Natural gas to propane
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For IPI Proflame 2 pilot IDV26 fireplace inserts

Conversion Kit to Natural Gas Proflame 2 (26IDV-CKNG2)

Gas conversion kit
Propane to natural gas
Complete with conversion instructions
Includes all necessary gas valve and pilot assembly conversion components
For IPI Proflame 2 pilot IDV26 fireplace inserts

Click to see Clean View Kit (Required to Complete)

Clean View Kit

	1 3/4" Deep Clean View Slim Front (I26CV1BL) Color: Black Size: 22 Inches x 35 Inches Low profile clean view appearance Measures 35 5/8" wide, 22 3/4" high, and 1 3/4" deep Designed to fit IDV26 series fireplace inserts
	3 1/2" Deep Clean View Slim Front (I26CV3BL) Color: Black Sleek satin black finish Size: 22 Inches x 35 Inches Low profile clean view appearance Measures 35 5/8" wide, 22 3/4" high, and 3 1/2" deep Designed to fit IDV26 series fireplace inserts
	Clean View Slim Picture Frame Front (I26CVPF1BL) Color: Black Size: 25 Inches x 35 Inches Four-sided picture frame design Perfect for installations with no raised hearth Measures 35 5/8" wide, 25 7/8" high, and 1 3/4" deep Designed to fit IDV26 series fireplace inserts
	Wide Clean View Front (I26CV2BL) Color: Black Size: 26 Inches x 44 Inches Low profile clean view appearance - wide version Measures 44 5/8" wide, 26 5/8" high, and 1 3/4" deep Designed to fit IDV26 series fireplace inserts
	Wide Clean View Picture Frame Front (I26CVPF2BL) Color: Black Size: 33 Inches x 44 Inches Four-sided wide picture frame design Perfect for installations with no raised hearth Measures 44 7/8" wide, 33 1/2" high, and 1 3/4" deep Designed to fit IDV26 series fireplace inserts

Click to see Surrounds

Surrounds

Slim Surround (I26S1BL)

Finish: Black
Measures 42" wide by 27 1/2" high
Fits only I26CV1 and CV3 series fireplace fronts
Slim design surround for use with IDV26 series fireplace inserts
Covers the gap between the insert and fireplace edges

Universal Surround (I26SUBL)

Finish: Black
Size: 35 Inches x 47 Inches
Multi-fit type surround for IDV26 series fireplace inserts
Can be used with any I26 series clean view fronts
Picture frame configuration dimensions: 47 1/2" wide by 35 5/8" high
Three-sided configuration dimensions: 47 1/2" wide by 28 5/8" high

Slim Picture Frame Surround (I26SPF1BL)

Finish: Black
Size: 29 Inches x 39 Inches
Measures 39 3/8" wide by 29 3/4" high
Covers the gap between the insert and fireplace edges
Fits only CV1 and CV3 series fireplace fronts
Slim picture frame design surround for use with IDV26 series fireplace inserts

Click to see Riser For Surrounds

Riser For Surrounds

Riser For I33S4028B Surround (I33R40)

Raises Coverage Height By 2.5"
Ideal for taller fireplace openings, allowing the insert to be closer to center height
Designed specifically for I33S4028B surround assemblies
Works with IDV33 series fireplace inserts

Riser For I33S4430B Surround (I33R44)

Raises Coverage Height By 2.5"
Ideal for taller fireplace openings, allowing the insert to be closer to center height
Designed specifically for I33S4430B surround assemblies
Works with IDV33 series fireplace inserts

Click to see Liner Kit

Liner Kit

3 Piece Refractory Liner (IDV26RL)

Color: Red
Installation hardware included
Durable cast refractory construction
Mimics the look of traditional running courses of brick
Designed to add a realistic appearance to the firebox interior
Designed specifically for IDV26 series fireplace inserts

3 Piece Porcelain Reflective Panel Liner (IDV26PRL)

Color: Reflective Black
Installation hardware included
Durable porcelain-coated steel finish
Amplifies the flame presentation via reflective qualities
Sleek modern appearance compliments fire glass installations
Designed specifically for IDV26 series fireplace inserts

Click to see Mantel Clearance Shield

Mantel Clearance Shield

Mantel Clearance Shield (I33CS)

Type: Mantel Clearance Shield
Mounts below the mantel shelf and deflects heat outward
Helps to maintain safe temperatures of combustible mantels
Designed for use with IDV26 series fireplace inserts

Click to see Log Bits Kit

Log Bits Kit

Four Piece Log Bits Kit (VLBIT4)

Designed to bolster the look of existing Kingsman log sets
Includes four large log chunks
Easy to install and arrange as desired

Six Piece Log Bits Kit (VLBIT6)

Designed to bolster the look of existing Kingsman log sets
Includes six large log chunks
Easy to install and arrange as desired

Click to see Thermostat

Thermostat

Wall Mount Thermostat- For Millivolt Units (Z2MT)

Simple on/off millivolt thermostat design
Easy to use digital control
Allows convenient operation of gas appliances
Simple to wire to existing millivolt systems

Programmable Digital Wall Mount Thermostat- For Millivolt Units (Z80PT)

Schedule programmable for desired operation
Works with Kingsman millivolt appliances
Easy to read digital LCD display

Click to see Remote Control

Remote Control

On/Off Remote Control for Millivolt/IPI Units (GFRC)

Simple on/off operation for millivolt appliances
Allows for the operation of the appliance without manual control
Included receiver easily mounts within the appliance chassis
Reliable RF transmitter operation

Thermostat Remote Control Millivolt/IPI Units (GTRC, EGTRC)

On/off operation with modulating thermostat control
Allows for the operation of the appliance without manual control
Included receiver easily mounts within the appliance chassis
Reliable RF transmitter operation

Thermostat On/Off modulating for Natural Gas/Propane Millivolt/IPI Units
(GTMRCN, GTMRCP, EGTMRCN, EGTMRCP)

On/off operation with modulating thermostat control
Allows for the operation of the appliance without manual control
Included receiver easily mounts within the appliance chassis
Reliable RF transmitter operation
Includes high/low modulating motor for natural gas and propane gas fireplaces

Wire Harness

Extension Wire Harness (1001-P904SI)

Kingsman 1001-P904SI 10-Foot Wire Harness for Modulating Remote Installation provides a premium accessory to be used with your fireplace remote system. Featuring a 10-foot length, this kit allows for easy installation of the wiring harness. This component is required for the IDV26 when an optional modulating remote is installed (Kingsman GTMRCN, GTMRCP, EGTMRCN, or EGTMRCP).

Type: Wire Harness
For use with GT Series Remote with Kingsman Stoves

Click to see venting products

venting

3/3" Vertical Vent Termination - IDVVT36
	3/3-Inch Vertical Chimney Vent Termination provides a premium installation component to be used with your fireplace
Flex Pipe Kit - IDVFK25
	Flexible Stove Pipe Kit provides a premium installation component to be used with your fireplace. Kit includes two 3" diameter x 25' liners.
Block Off Plate - IDVLCP
	Block Off Plate for Lower Chase provides a premium installation component to be used with your fireplace and this block off plate is intended to be used with Kingsman's Millivolt Control Collection.
3" Flex Connector - ZDV3FC
	This chimney vent is provided with a flex connector that measures 3-Inches in diameter. This handy vent won't only keep your living room from being damaged but is additionally flexible enough to keep from being easily damaged itself.

DOWNLOAD
