Firegear's versatile stainless steel gas fire pit burner system, a perfect addition to elevate your outdoor ambiance. Designed with precision and durability, this sleek burner system offers a range of options to suit your preferences.

Choose from various ignition systems, starting with the standard match throw system for simplicity, or upgrade to the safety ignition for added convenience and peace of mind. For the pinnacle of ease, opt for the AWS System, allowing effortless control and customization. With a selection of sizes and formats, including round, square, or linear, you can customize your fire pit to harmonize with any outdoor space. Embrace the warmth, style, and innovation of our stainless steel gas fire pit burner system and create memorable moments around the fire.

What's Included

• H-Shaped Burner
• Linear Drop-In Pan
• TPSI Ignition System

Not Included (Sold Separately)

• Glass Windshield (GWS-4119)
• Stainless Steel Lid (LID-LOF3614)
• Flexframe Installation Collar

• Paver Control Panel Kit

• Paver Vent Kit

• LP Conversion Kit
• Media Options


Features

• Available in Natural Gas and Liquid Propane models
• Stainless steel H-shaped burner
• Linear stainless steel drop-in pan with lip
• Easy ignition with Battery Spark Igniter (included). Thermocouple Piloted System with Safety Valve turns gas off when loss of flame.

Specifications

Item Number	LOF-3614HTPSI-N
Series	Stainless Steel Series
Product Type	Burner System
Fuel Type	Natural Gas
BTU	125,000
Burner Type	H Burner
Burner Dimensions	33" x 10"
Pan Dimensions	36” x 14”
Ignition System	Thermocouple Piloted Safety Ignition
Required Media	30 lbs Lava Rock | 70 lbs Glass | 30 lbs Lava Stones

Warranty

Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period:

BURNER SYSTEMS | BURNERS | COMPONENTS | ACCESSORIES

	Consumer Applications	Commercial Applications
Construction and Manufacturer Defects	Lifetime	2 Years
Stainless Steel Burners and Pans	Lifetime	2 Years
Pro Series Burners	Lifetime	2 Years
Gas Valve, Spark Igniter, and Pilot Assemblies	5 Years	2 Years
AWS Electronic Ignition Systems (12 VAC, 24 VAC, 30 VAC)	5 Years	2 Years
TPSI Electronic Components	5 Years	2 Years
MT Components (Key Valve)	5 Years	2 Years
Refractory Gas Log Sets	5 Years	2 Years
Skytech Manufactured Optional Controls	5 Years	2 Years

Documents & Files

• Product Guide
• Stainless Steel Lid Installation Instructions
• Paver FlexFrame Installation Instructions
• Paver Vent Kit Installation Instructions
• Media Use Guide
• Warranty Guide

Frequently Asked Questions

What is Thermocouple Piloted Safety Ignition (TPSI)? TPSI Ignition System Thermocouple Piloted System with Safety Valve turns gas off when loss of flame Easy ignition with Battery Spark Igniter (included) TPSI system with Safety Valve turn gas off when pilot flame goes out Robust ignition system with full BTU throughput How it Lights Press and hold Red Ignitor button to spark While holding the red ignitor button, Push in slightly & rotate the Control Knob from the OFF to PILOT LIGHT position Release the Ignitor Button while Continuing to depress the Control Knob for 30-60 seconds. Release the Control Knob Confirm your pilot light is on. Turn Control Knob from PILOT LIGHT to the ON position to ignite your burner.
