Introducing our Pro Brass Gas Fire Pit Burner Systems, a true testament to elegance and performance. Crafted with precision using High-Quality Brass, this burner system adds a touch of luxury to your outdoor space.

Choose from a range of ignition systems, starting with the standard match throw system for simplicity, or upgrade to the safety ignition for added convenience and peace of mind. For the pinnacle of ease, opt for the AWS System, ensuring effortless control and customization. The unique injector style orifice of our burner system creates a mesmerizing flame that is truly one of a kind, setting the stage for unforgettable moments around the fire. Whether you prefer a round, square, or linear format, our Pro Brass gas fire pit burner system offers unmatched versatility and style. Elevate your outdoor ambiance with the finest quality and aesthetics - choose our Pro Brass gas fire pit burner system for an unparalleled experience.

What's Included

• Square Drop-In Pan (SS)
• Snowflake Brass Burner
• AWS Ignition System

Not Included (Sold Separately)

• Glass Windshield (GWS-2424)
• Stainless Steel Lid (LID-20S)

• Flexframe Installation Collar

• Paver Control Panel Kit

• Paver Vent Kit

• LP Conversion Kit

• Media Options

Features

• Available in Natural Gas and Liquid Propane models
• Pro Series brass Snowflake burner

• Stainless steel square drop-in pan

• AWS fully electronic ignition - 30VDC (Requires 120Vac) - Assembled (GOE-30VDC) power supply, AWS control panel with On/OFF weatherproof switch.


Specifications

Item Number	FPB-20SPSSF11AWS-N
Series	Stainless Steel Series
Product Type	Burner System
Fuel Type	Natural Gas
BTU	50,000
Burner Type	Snowflake Brass
Burner Diameter	11"
Pan Size	20"
Ignition System	All Weather Electronic

Media Use Guide

Lava Rock Only	10 lbs.
Lava Rock as a Base	10 lbs.
Glass (on top of Lava Rock)	20 lbs.
Lava Stones (on top of Lava Rock)	15 lbs.
Glass Only	50 lbs.

Warranty

Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period:

BURNER SYSTEMS | BURNERS | COMPONENTS | ACCESSORIES

	Consumer Applications	Commercial Applications
Construction and Manufacturer Defects	Lifetime	2 Years
Stainless Steel Burners and Pans	Lifetime	2 Years
Pro Series Burners	Lifetime	2 Years
Gas Valve, Spark Igniter, and Pilot Assemblies	5 Years	2 Years
AWS Electronic Ignition Systems (12 VAC, 24 VAC, 30 VAC)	5 Years	2 Years
TPSI Electronic Components	5 Years	2 Years
MT Components (Key Valve)	5 Years	2 Years
Refractory Gas Log Sets	5 Years	2 Years
Skytech Manufactured Optional Controls	5 Years	2 Years

Documents & Files

• Product Guide
• Stainless Steel Lid Installation Instructions
• Paver FlexFrame Installation Instructions
• Paver Control Panel Installation Instructions
• Paver Vent Kit Installation Instructions
• Media Use Guide
• Warranty Guide


Videos

Frequently Asked Questions

What is All-Weather Electronic Ignition Systems (AWS)? Every project is different with its own set of unique challenges. That’s why versatility is paramount when designing and constructing your outdoor project. Firegear Outdoors has developed a new system with the capability to satisfy even the most demanding jobs. This new all weather electronic ignition system will make designing your project easier as well as making installation a breeze. AWS | Single Fire Feature Used for a single fire feature. Can only be installed in fire features that are greater than 10 feet away from a pool or spa. All components can be housed underneath the burner AWS | Multiple Fire Features Used when running 1 – 4 fire features. Also used when running a single or multiple fire features within 5 feet of a pool / spa. One kit per fire feature. One power supply (sold separately) for every 4 fire features.
