Introducing our Pro Brass Gas Fire Pit Burner Systems, a true testament to elegance and performance. Crafted with precision using High-Quality Brass, this burner system adds a touch of luxury to your outdoor space.

Choose from a range of ignition systems, starting with the standard match throw system for simplicity, or upgrade to the safety ignition for added convenience and peace of mind. For the pinnacle of ease, opt for the AWS System, ensuring effortless control and customization. The unique injector style orifice of our burner system creates a mesmerizing flame that is truly one of a kind, setting the stage for unforgettable moments around the fire. Whether you prefer a round, square, or linear format, our Pro Brass gas fire pit burner system offers unmatched versatility and style. Elevate your outdoor ambiance with the finest quality and aesthetics - choose our Pro Brass gas fire pit burner system for an unparalleled experience.

What's Included

• Square Drop-In Pan (SS)
• Brass Burning Spur
• AWS Ignition System

Not Included (Sold Separately)

• Glass Windshield (GWS-2424)
• Stainless Steel Lid (LID-20S)
• Flexframe Installation Collar

• Paver Control Panel Kit

• Paver Vent Kit

• Media Options

Features

• Available in Natural Gas and Liquid Propane models
• Pro Series brass Snowflake burner

• Stainless steel square drop-in pan

• TPSI Ignition with battery-powered spark igniter.


Specifications

Model	FPB-20SPSBR14TPSI-N(P)
Product Type	Fire Pit Burner System
Fuel Type	Natural Gas, Propane
BTU	125,000
Pan Size	20"
Burning Spur Size	14"
Ignition System	Thermocouple Piloted Safety Ignition System

Warranty

Firegear Outdoors hereby warrants to the end user that products will be free from material and workmanship defects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period:

BURNER SYSTEMS | BURNERS | COMPONENTS | ACCESSORIES

	Consumer Applications	Commercial Applications
Construction and Manufacturer Defects	Lifetime	2 Years
Stainless Steel Burners and Pans	Lifetime	2 Years
Pro Series Burners	Lifetime	2 Years
Gas Valve, Spark Igniter, and Pilot Assemblies	5 Years	2 Years
AWS Electronic Ignition Systems (12 VAC, 24 VAC, 30 VAC)	5 Years	2 Years
TPSI Electronic Components	5 Years	2 Years
MT Components (Key Valve)	5 Years	2 Years
Refractory Gas Log Sets	5 Years	2 Years
Skytech Manufactured Optional Controls	5 Years	2 Years

Documents & Files

• Product Guide
• Stainless Steel Lid Installation Instructions

• Glass Windshield Lid Installation Instructions

• Paver FlexFrame Installation Instructions
• Paver Vent Kit Installation Instructions
• Media Use Guide
• Warranty Guide


Frequently Asked Questions

What is Thermocouple Piloted Safety Ignition (TPSI)? TPSI Ignition System Thermocouple Piloted System with Safety Valve turns gas off when loss of flame Easy ignition with Battery Spark Igniter (included) TPSI system with Safety Valve turn gas off when pilot flame goes out Robust ignition system with full BTU throughput How it Lights Press and hold Red Ignitor button to spark While holding the red ignitor button, Push in slightly & rotate the Control Knob from the OFF to PILOT LIGHT position Release the Ignitor Button while Continuing to depress the Control Knob for 30-60 seconds. Release the Control Knob Confirm your pilot light is on. Turn Control Knob from PILOT LIGHT to the ON position to ignite your burner.
