SKU:DVCT30CBN95N
Empire Rushmore Clean Face 30" TruFlame Multi Function Thermostat Remote Control, Natural Gas Direct Vent Fireplace Insert
Empire Rushmore Clean Face 30" TruFlame Multi Function Thermostat Remote Control, Natural Gas Direct Vent Fireplace Insert
Log Set (Required)
-- Please Select --
No, Thank You
Decorative Liner (Required)
-- Please Select --
No, Thank You
3-Sided Black Surround (Required)
-- Please Select --
No, Thank You
Custom Surround
-- Please Select --
No, Thank You
Black Shroud
-- Please Select --
No, Thank You
Conversion Kit
-- Please Select --
No, Thank You
Beveled Frames
-- Please Select --
No, Thank You
Decorative Frames & Insets
- Free Shipping on Orders Over $300
- Same-Day Order Processing
A Direct-Vent system uses two vent pipes. One draws air in from outdoors to support combustion. The other exhausts the by-products of combustion to the outside. The two vent pipes may be concentric (exhaust pipe within a larger diameter intake pipe) or co-linear (separate pipes of about the same size).
Combustion takes place inside a sealed chamber – with a glass front in the case of a fireplace. Room air circulates around the combustion chamber, often assisted by a blower, to heat the room.
A DV system is often installed along an outside wall to simplify the vent run, but can also be installed elsewhere in the home and vented through the roof.
Rushmore Direct-Vent Inserts
A Direct-Vent Fireplace Insert turns your existing wood-burning fireplace into an efficient gas-fired heat source. Direct-Vent Fireplace Inserts are classified as zone heating appliances. Zone heating is inherently more efficient than your existing wood-burning fireplace or your central furnace.
Rushmore Clean-Face Direct Vent Insert (DVCT30CBN)
Rushmore fireplace inserts feature the TruFlame system – a combination of technology and aesthetics to create realistic flames and a glowing ember bed, mimicking a natural wood fire. Available in two sizes, 30 and 35, these inserts turn your wood-burning fireplace into an attractive and efficient focal point. The multifunction remote operates as a conventional thermostat, a Smart Thermostat – which modulates flame height as the room reaches the desired temperature, or as a manual control. The remote also operates the included accent light and blower.
What's Included
- Rushmore Clean Face Fireplace Insert
- Blower
- Accent Light
- Ceramic Glass
- Barrier Screen (Fine Mesh)
- Multi-Function remote control
Not Included (Sold Separately)
- Logs (Required)
- Liner (Required)
- Surround (Required)
- Forged Iron Fronts and Insets
- Beveled Frames
- Surrounds and Shroud
- Gas Conversion Kit
Features
- Multi-Function remote to control (Variable flame height, Overhead dimmer lighting and Variable-speed blower)
- The TruFlame system combines technology with aesthetics to create
truly realistic flames and a glowing ember bed, reminiscent of a wood fire - Available in two sizes, 30 and 35, these inserts turn your wood-burning fireplace into an attractive and efficient focal point
- The multifunction remote operates as a conventional thermostat, a Smart Thermostat – which modulates flame height as the room reaches the desired temperature, or as a manual control
- The remote also operates the included accent light and blower
Specifications
Model | DVCT30CBN95 |
Max BTU (w/both burners) | 30,000 |
Min BTU (w/both burners) | 19,500 |
Min BTU (front burner only) | 8,500 |
Vent Type | Direct Vent |
Type of Gas | Natural Gas |
Venting | 3 x 4 Flex |
Installation | Insert |
KWH (Maximum) | 8.79 |
KWH (Minimum) | 2.49 |
Orifice - Front | #52 |
Orifice - Rear | #47 |
Air Shutter Opening Front | Fully Closed |
Air Shutter Opening Rear | Fully Closed |
Gas Inlet Shutoff Valve (Pipe) | 3/8" MIF |
Gas Supply Pressure (Inches Water Column) |
Maximum | 14 |
Minimum | 4.5 |
Manifold | 3.5 |
Dimensions
Ceramic Glass Width | 25" |
Ceramic Glass Height | 15" |
Width | 31" |
Height | 19" |
Depth | 18" |
Warranty
- 10-year limited warranty on combustion chamber, limited lifetime on glass
- All remote controls carry a one-year limited warranty
- All other parts carry a three-year limited warranty
Documents & Files
-
Rushmore Brochure
- Rushmore Owner's Manual
- Rushmore Installation Guide
- Rushmore Architecture
- Rushmore Clean-Face Direct-Vent Driftwood Log Set -30
- Rushmore Clean-Face Direct-Vent Traditional Charred Log Set – 30
- Natural Gas to Propane Conversion Kit for the Rushmore Inserts
- Rushmore Clean-Face Direct-Vent Liner Kits
Frequently Asked Questions
Can I buy a fireplace online and install it myself?
We highly recommend a certified professional install all of our units. Any issues that arise from improper installation will not be covered under warranty. |
Does our product work during a power outage?
Yes, most of our appliances have the ability to be used in a power outage situation please see a local dealer for more information. |
What is the difference between Millivolt and electronic ignition fireplaces?
Millivolt fireplaces use the electricity produced by a standing pilot to operate the fireplace. Electronic ignition fireplaces rely on a power source to power the fireplace, this can be house voltage as well as battery voltage. |
Can I use a Wi-Fi Thermostat with my unit?
Our units are designed to be operated by millivolts or low voltage, most Wi-Fi thermostats use 24volts and are not compatible. |
Where can I find my model and serial number?
There is a rating plate attached to the valve of your appliance that will have the model and serial number information. |
Can you tell me how old my unit is?
Once you locate your rating plate the serial number will help identify the age, the first two digits of the serial number denote the year of manufacture (21, 20, 19...) the next two digits identify the week of that year that the unit was built. |
What is the difference between a fireplace, a firebox, and an insert?
Fireplaces are designed to be installed into a framed opening with specific clearances to combustibles. Fireboxes are just like Fireplaces in terms of where they can be installed but in addition a burner and a set of logs is required to finish off the unit. Inserts are designed to be installed directly into an existing wood burning fireplace that meets all standards of construction. |
