SKU:VFPC20IN33N
Empire Innsbrook 27" Millivolt Control With On/Off Switch, Natural Gas Vent Free Small Fireplace Insert
Empire Innsbrook 27" Millivolt Control With On/Off Switch, Natural Gas Vent Free Small Fireplace Insert
Cast Iron Surround
-- Please Select --
No, Thank You
Adapter Required for Cast Iron Surround
-- Please Select --
No, Thank You
Metal Surround
-- Please Select --
No, Thank You
Shroud
-- Please Select --
No, Thank You
Control Options
Couldn't load pickup availability
- Free Shipping on Orders Over $300
- Same-Day Order Processing
Innsbrook Vent-Free Fireplace Inserts
Empire offers the Innsbrook Vent-Free Inserts in two sizes (20,000 BTUs and 28,000 BTUs) so you are sure to find one to fit your existing wood-burning fireplace.
Our Innsbrook Vent-Free inserts feature Banded Brick Liners, a fine mesh barrier screen, and hand-painted ceramic fiber logs on a variable-flame burner. The unique Slope Glaze Burner produces natural flickering flames.
The Innsbrook Insert lights at the flick of a switch to produce consistent, reliable heat, even when electric power fails. Add the convenience of an optional thermostat, wireless wall thermostat, remote control, or thermostat remote control, and enjoy all the comfort of a warm fire without the mess and hassle.
Innsbrook Vent-Free Inserts (VFPC)
Innsbrook Vent-Free inserts feature Banded Brick Liners, with hand-painted ceramic fiber logs nestled atop the variable-flame burner, to create an exceptionally attractive traditional fireplace. The unique Slope Glaze Burner produces natural flickering flames.
Every Innsbrook Vent-Free Insert also includes a blower and fine mesh barrier screen.
What's Included
- Innsbrook Vent Free Fireplace Insert
- Banded Brick Ceramic Liner
- Fine Mesh Barrier Screen
- On/Off Switch
- Blower
- Log Set
Not Included (Sold Separately)
- Control Options
- Cast Iron Surround
- Surround Adaptor
- Metal Surround and Shroud
Please Note
- One surround is required to complete this unit.
- Metal surrounds do not include a bottom cover. For in-wall installation (not on a hearth) order a custom 4-sided surround.
- SH1BL Shroud helps conceal larger fireplace opening.
Features
- Opening -14 5/8 H x 25 7/8 W
- Unmatched efficiency – 99.9%
- Offers the most installation versatility
- Usually less expensive to buy and to install
- Can operate with a remote or thermostat
- Most systems can provide live-saving heat during a winter power outage
- This unit installs as an insert inside an existing fireplace
- This same unit installs as a vent-free fireplace
- Innsbrook Vent-Free inserts feature Banded Brick Liners, a fine mesh barrier screen, and hand-painted ceramic fiber logs on a variable-flame burner
Specifications
| Model | VFPC20IN33 |
| Vent Type | Vent Free |
| Installation | Zero Clearance |
| Fuel Type | Natural Gas |
| Ignition Type | Millivolt |
| Input BTU/Hr Maximum | 20,000 |
| Input BTU/Hr Minimum | 14,000 |
| Orifice | 2.1mm |
| Air Shutter Opening | 1/8" |
Dimensions
| Front Width | 27" |
| Rear Width | 16" |
| Height | 19" |
| Depth | 13" |
Warranty
- All parts carry a five-year limited warranty with a five-year limited labor warranty
- All remote controls carry a one-year limited warranty
Documents & Files
- Product Brochure
- Product Installation Instructions
- Installation Instructions Surround
- Specification Sheet VFPC20
Frequently Asked Questions
Can I buy a fireplace online and install it myself?
We highly recommend a certified professional install all of our units. Any issues that arise from improper installation will not be covered under warranty. |
Does our product work during a power outage?
Yes, most of our appliances have the ability to be used in a power outage situation please see a local dealer for more information. |
What is the difference between Millivolt and electronic ignition fireplaces?
Millivolt fireplaces use the electricity produced by a standing pilot to operate the fireplace. Electronic ignition fireplaces rely on a power source to power the fireplace, this can be house voltage as well as battery voltage. |
Can I use a Wi-Fi Thermostat with my unit?
Our units are designed to be operated by millivolts or low voltage, most Wi-Fi thermostats use 24volts and are not compatible. |
Where can I find my model and serial number?
There is a rating plate attached to the valve of your appliance that will have the model and serial number information. |
Can you tell me how old my unit is?
Once you locate your rating plate the serial number will help identify the age, the first two digits of the serial number denote the year of manufacture (21, 20, 19...) the next two digits identify the week of that year that the unit was built. |
What is the difference between a fireplace, a firebox, and an insert?
Fireplaces are designed to be installed into a framed opening with specific clearances to combustibles. Fireboxes are just like Fireplaces in terms of where they can be installed but in addition a burner and a set of logs is required to finish off the unit. Inserts are designed to be installed directly into an existing wood burning fireplace that meets all standards of construction. |
