Empire 40" Rushmore See-Through Direct Vent Gas Fireplace

A Direct-Vent system uses two vent pipes. One draws air in from outdoors to support combustion. The other exhausts the by-products of combustion to the outside. The two vent pipes may be concentric (exhaust pipe within a larger diameter intake pipe) or co-linear (separate pipes of about the same size).

Combustion takes place inside a sealed chamber – with a glass front in the
case of a fireplace. Room air circulates around the combustion chamber, often assisted by a blower, to heat the room.

A DV system is often installed along an outside wall to simplify the vent run,
but can also be installed elsewhere in the home and vented through the roof.

Advantages:

• Good efficiency – 60 to 80%
• Good heat output with thermal transfer through the glass and air circulation
• Separates room air from combustion air
• May be used as primary heat source
• Can operate with a remote or thermostat
• Most systems can provide life-saving heat during a winter power outage

With its massive log set, deep ember bed, dual burner and huge ceramic glass front, the Rushmore is one great-looking fireplace, but what you can’t see makes this fireplace even more impressive.

Empire’s TruFlame Technology ensures maximum flames and ember glow with minimum emissions.

The system starts with independently controlled front and rear burners set in a large ember bed.

The burners create a tall lively fire that dances and curls around the hand-painted ceramic fiber logs – generating a continuous tableau of flame shapes and light patterns.

Rushmore’s product line up is growing! Combining a see-through unit with Tru-Flame technology allows the most realistic flame to be enjoyed in two rooms of any home.

The Rushmore 40 See-Through features a dual burner that creates a lively fire, InvisiMesh that provides a crystal clear 40-inch viewing area, and an optional stainless steel outdoor kit that can add comfort to any outdoor seating area.

• Up to 60,500 BTUs
• Ceramic Glass: 31 1/2 H x 37 3/8 W

*Please Note: This model requires the purchase of the interior liner and log set (not included) ; sold separately.

*Also Note: This model can also be used as an indoor / outdoor fireplace with the purchase of a stainless steel trim kit. Please Check Options & Accessories section for more details.

Includes:

• Fine Mesh Barrier
• Non-Combustible Board
• Multi-Function remote to control
  • Front and rear burner 6-step variable flame height
  • Independent Rear burner on/off (70% turn down)
  • Accent lighting on/off with 6-step dimming
• TruFlame Technology
  • Catalyst allows large flame
  • extensive ember bed and clean burn

• Liner
• Log Set

CA Residents: See Prop 65 WARNING.

OPTIONS & ACCESSORIES

*Please Note: Log set and Liner required to complete this unit.

Traditional Charred Log Set Size: 40 Inches Color: Brown Realistic birch appearance Made of burncrete material Specifically designed for 40" Empire Rushmore direct-vent see-through fireplace

	Black Andirons Finish: Black Helps to provide the appearance of a real wood fire Designed to fit Rushmore See-Through Direct Vent Fireplace
	Conversion Kit Propane to Natural Gas Natural Gas to Propane Specifically designed for 40" Empire Rushmore see-through fireplace Comes with everything you need to complete the gas conversion process

Click to see Liners

	Old World Stone Size: 40 Inches Color: Stone Old world stone finish Made of ceramic fiber material Specifically designed for 40" Empire Rushmore direct-vent see-through fireplace
	Fire Cracked Brick Size: 40 Inches Color: Red Cracked red fire brick finish Made of ceramic fiber material Specifically designed for 40" Empire Rushmore direct-vent see-through fireplace
	White Herringbone Brick Size: 40 Inches Color: White Made of ceramic fiber material Whitewashed herringbone brick finish Specifically designed for 40" Empire Rushmore direct-vent see-through fireplace
	Black Porcelain Size: 40 Inches Color: Black Black reflective liner Includes matte black ceiling and floor Specifically designed for 40" Empire Rushmore direct-vent see-through fireplace

Click to see Decorative Front and Insets

	Forged Iron Frame Type: Forged Iron Frame Finish: Black / Distressed Pewter / Oil-Rubbed Bronze Can be used with matching insets Specifically designed for 40" Empire Rushmore direct-vent fireplace and see-through fireplace
	Forged Iron Inset (Arch) Type: Forged Iron Inset Style: Arch Finish: Black / Distressed Pewter / Oil-Rubbed Bronze Must be used with matching frame Specifically designed for 40" Empire Rushmore direct-vent fireplace and see-through fireplace Please Note: Inset Required Matching Forged Iron Frame
	Forged Iron Inset (Rectangle) Type: Forged Iron Inset Style: Rectangle Finish: Black / Distressed Pewter / Oil-Rubbed Bronze Must be used with matching frame Specifically designed for 40" Empire Rushmore direct-vent fireplace and see-through fireplace Please Note: Inset Required Matching Forged Iron Frame

Click to see Beveled and Exterior Frame

	Beveled Frame Type: Beveled Frame Finish: Textured Black / Oil-Rubbed Bronze / Brushed Nickel Beveled frame edging to give your fireplace a decorative finish Specifically designed for 40" Empire Rushmore direct-vent fireplace and see-through fireplace
	Stainless Steel Frame for Exterior Installation Type: Frame Size: 40 Inches Finish: Stainless Steel Specifically designed for 40" Empire Rushmore see-through fireplace Designed for exterior installation

Click to see Heat Management Options

	Heat Management Kit Gravity heat management Part of the heat management system (Includes 36" Plenum and 10' Flex)
	External Forced Air Heat Management External forced air kit Part of the heat management system Requires the Empire Flex Vent Kit for Forced Air Kit
	Flex Vent Kit for Forced Air Kit Flex Vent Kit (25' Flex and Clamps) Part of the heat management system This flex vent kit is required for forced air kit
