Empire 26" Vail Vent-Free Fireplace Special Edition with Mantel Combination - Millivolt

A Vent-Free system uses room air for combustion and delivers 99.9% of the available heat energy directly to the room. Vent-Free systems have an unmatched safety record, thanks in part to their clean-burning technology and their Oxygen Depletion Sensor, which instantly shuts off the valve if oxygen in the room drops to and unsafe level. Because no venting is required, Vent-Free systems offer more installation options.

Vent-Free systems are limited to 40,000 Btu and must be operated as supplemental heating sources in conjunction with a central furnace that circulates air.

Advantages

• Unmatched efficiency – 99.9%
• Offers the most installation versatility
• Usually less expensive to buy and to install
• Can operate with a remote or thermostat
• Most systems can provide live-saving heat during a winter power outage



Vail Vent-Free Fireplaces

At 99.9 percent efficient, the Vent-Free Vail Fireplace delivers more heat for your energy dollars – 32,000 Btu for the Vail 32 and 36,000 Btu for the Vail 36. Ceramic glazed pellets in the burner tumble and swirl the gas to produce a natural flickering flame.

The Vail 24 delivers the beauty of hand-painted ceramic fiber logs and natural flickering flames to dens, halls, and even bedrooms.

The Vail 26 Special Edition is the American-made fireplace system that ships complete in one package and is also offered as a separate fireplace – perfect for built-in and custom mantel applications.

Vail 26 Special Edition (VFD26FM)

The Vail 26 Special Edition is the American-made fireplace system that ships complete in one package – fireplace, assembled mantel, Flint Hill log set with 20,000 Btu vent-free Contour burner, matte black hood, frame, and louvers – even glowing embers.

This package system installs in as little as 30 minutes, minimizing labor costs. A total mantel footprint of just over 17 by 45 inches makes the Vail 26 Special Edition ideal for tight spaces and small rooms.

The Vail 26 Special Edition is available in three mantel colors – nutmeg, cherry, and white – and in modulating hydraulic thermostat and Millivolt control. The Millivolt system allows you to add a wall thermostat, remote control, or thermostat remote control.

FEATURES

• Up to 20,000 BTUs
• Available in 2 mantel colors – cherry and white
• Vent-free units do not require any venting products
• This package system installs in as little as 30 minutes, minimizing labor costs



Includes:

• Mantel
• Ceramic Fiber Log Set
• Hood, Outer Frame, and Louvers in Matte Black

Specifications

Model	VFD26FM
Actual Dimensions	30 1/4 H x 30 W x 13 1/8 D
Framing Dimensions	30 3/8 H x 30 1/4 W x 13 1/4 D
Fuel Type	Natural Gas / Propane
Vent Type	Vent-Free
Ignition Type	Millivolt with On/Off Switch
Installation Type	Zero Clearance
Style	Traditional
Input BTU/HR (KW/H) Max/Min (Propane)	20,000/14,000
Input BTU/HR (KW/H) Max/Min (Natural Gas)	20,000/14,000

CA Residents: See Prop 65 WARNING.

DOWNLOADS

• Product Brochure
• Specification Sheet
• Installation Instructions & Owner's Manual



OPTIONS & ACCESSORIES

Liner Kits

	Auto Blower Variable-speed blower Includes temperature switch Increases overall working efficiency of the fireplace
	Wire extension kit for FBB4 variable-speed blower
	Flexible 24" Stainless Steel Gas Line Stainless steel flexible gas line 24" length Ideal for the connection of a variety of gas appliances Use to easily connect gas logs to existing fireplace gas connection
	Ember Kit Comes with Traditional Log Burnt Log Pieces, White Ash, and Lava Rock Included *This kit is not for use atop a burner.
	Platinum Embers Platinum glowing fireplace embers Can be placed directly on the burner Includes approximately 1 gram of ember material

• All parts carry a five-year limited warranty with a five-year limited labor warranty.
• All remote controls carry a one-year limited warranty.
