EcoSmart Fire Linear 65 64" Black Outdoor Fire Pit Kit with Gas LP/NG Burner by Mad Design Group
EcoSmart Fire Linear 65 64" Black Outdoor Fire Pit Kit with Gas LP/NG Burner by Mad Design Group
Couldn't load pickup availability
- Free Shipping on Orders Over $400
- Same-Day Order Processing
Contemporary elegance Fire Pit Kit.
With an elegant curved metal tray that creates a softer, organic look, the Linear Curved 65’s single flame is powered by an award-winning XL900 ethanol burner or UTL listed gas burner. A clean linear design and black glass charcoal softened by the curve of the metal tray at each end, combined with golden flickering flames create a stylish yet warm and organic look.
O-TL Listed in accordance with UL 1370.
What's Included
- G35 Gas Burner
- Inset Metal Tray
- Black Glass Charcoal
- Gas burner assembly
Not Included (Sold Separately)
- XL900 Burner Cover
- L65 Cover Plate
- L1080 Fire Screen
Features
Visual appeal
A clean linear design and black glass charcoal softened by the curve of the metal tray at each end, combined with golden flickering flames create a stylish yet warm and organic look.
Flexible Heat Output
Ranging from 20,000 BTUs (ethanol) up to 65,000 BTUs (gas), our fire pit kits are versatile in warm or cold environments.
Easily integrated
Outdoor Fire Pit Kits easily integrate with non-combustible surfaces including stone countertops, concrete surfaces, brick and tiled tops.
Three Fuel Options
Eco-friendly ethanol is a sustainable and responsible fuel source suitable for indoor or outdoor installation. Powered by natural gas or propane, our outdoor fire pits operate with a convenient push button ignition.
Year-round beauty
The design simplicity of our outdoor fire pits enhance the look and feel of any style of space at any time of the year.
Created to last
Quality long-lasting materials including stainless steel and toughened glass ensure exceptional durability for indoor or outdoor installation.
Tested World Wide
Our collection has been thoroughly tested against a number of global standards and are UL Listed in the USA, Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.
Specifications
| Weight | 79.15lb [35.90kg] |
|---|---|
| Application | Indoor & Outdoor |
| Material | Stainless Steel Grade 304, Toughened Glass |
| Color | Black |
Fuel Efficiency
|
Minimal Room |
Outdoor Only |
|
Thermal Output |
65000 BTU/h |
|
Burn Time |
NG Burner: Unlimited Hours / Tank LP Burner: 7-20 Hours / Tank |
*Please Note: "These values are indicative only and may vary depending on the model purchased, installation environment, and the composition of the e-NRG bioethanol sourced in each country."
Dimensions
| Width | 17.8in [451mm] |
| Height | 12.2in [310mm] |
| Depth | 64.2in [1630mm] |
Technical Drawings
|
Front View |
![]() |
|---|---|
| Top View |
|
| Side View | ![]() |
Warranty
![]() |
Stainless steel parts including raw, linished and powder coated: 2 Years from Date of Purchase |
![]() |
Mild steel including powder coated and chrome plated, Cement, Glass, Leather, Fabric and MDF (Painted OR Cement Rendered): 1 Year from Date of Purchase |
Documents & Files
- Download Installation and Operation Manual
- Download Burner Manual
- Download Specs Sheet
- Download Look Book
*Note: "Read the manual carefully before operating the burner. Physical model dimensions should be verified against cut out dimensions BEFORE installation begins to confirm tolerances align."
