A Fire Pit Kit for gathering around.

The EcoSmart Round 20 Fire Pit Kit’s curved compact design and single flame powered by gas or ethanol create an inviting fire pit for smaller, more intimate spaces. The rounded fire pit style means it can be used as a design element to create a central focal point or to soften and enhance the look and feel of small and intimate interior or outdoor settings.

O-TL Listed in accordance with UL 1370.

What's Included

• G16 Gas Burner
• Inset Metal Tray
• Black Glass Charcoal
• Gas burner assembly
• AB8 Efficiency Ring


Not Included (Sold Separately)

• e-NRG Bioethanol Fuel
• R400 Fire Screen
• AB8 Burner Cover
• R20 Cover Plate
• R530 Fire Screen

Features

Curve appeal

The rounded fire pit style means it can be used as a design element to create a central focal point or to soften and enhance the look and feel of small and intimate interior or outdoor settings.

Design freedom

The design of our ethanol or gas Fire Pit Kits make it perfect for installing into custom-built round settings in your choice of non-combustible finish including stone, concrete, brick and tiles.

Year-round enjoyment

The Round 20 Ethanol Fire Pit Kit has been designed to be enjoyed year-round, indoors and outside.

Three Fuel Options

Powered by plants such as sugar cane or corn, ethanol is a sustainable fuel source suitable for indoor or outdoor installation. With a simple push button ignition, our gas fire pits provide higher heat and added convenience in outdoor spaces.

Clean Burning Flame

Our ethanol and gas fire pits, produce no smoke, no soot, and no ash - keeping your home safe from harmful emissions.

Enduring appeal

Four long-lasting materials - stainless steel, metal, toughened glass and black glass charcoal - ensure exceptional durability for our indoor and outdoor fire pits.

Tested World Wide

Our collection has been thoroughly tested against a number of global standards and are UL Listed in the USA, Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.

Specifications

Weight	48.50lb [22kg]
Application	Indoor & Outdoor
Material	Stainless Steel Grade 304, Toughened Glass
Color	Black

Fuel Efficiency

Minimal Room	Outdoor Only
Thermal Output	65000 BTU/h
Burn Time	LP Burner: 7-20 Hours / Tank NG Burner: Unlimited Hours / Tank

*Please Note: "These values are indicative only and may vary depending on the model purchased, installation environment, and the composition of the e-NRG bioethanol sourced in each country."

Dimensions

Width	24.8in [630mm]
Height	13.3in [339mm]
Depth	24.8in [630mm]

Technical Drawings

Side View
Top View

Warranty

	Stainless steel parts including raw, linished and powder coated: 2 Years from Date of Purchase
	Mild steel including powder coated and chrome plated, Cement, Glass, Leather, Fabric and MDF (Painted OR Cement Rendered): 1 Year from Date of Purchase

Documents & Files

• Download Installation and Operation Manual
• Download Burner Manual
• Download Specs Sheet
• Download Look Book

*Note: "Read the manual carefully before operating the burner. Physical model dimensions should be verified against cut out dimensions BEFORE installation begins to confirm tolerances align."
