SKU:LANGLEY-36-NG
Sierra Flame by Amantii 36" Langley Direct Vent Linear Gas Fireplace
Sierra Flame by Amantii 36" Langley Direct Vent Linear Gas Fireplace
Couldn't load pickup availability
- Free Shipping on Orders Over $300
- Same-Day Order Processing
DESIGN INTEGRITY, QUALITY CRAFTSMANSHIP & ATTENTION TO DETAIL
The Langley 36 is a true linear gas fireplace available at builder pricing. This unit might be shallow but this fireplace gives you all the advantages and beauty of our linear electric fireplaces.
At only 8 3/4” deep the langley is one of the shallowest linear units on the market.
Excellent choice for new home construction and renovations.
Featuring borosilicate glass that will not shatter and can tolerate the heat produced from the stainless steel burner.
FEATURES
Standard System
- Shallow depth design
- Linear style burner
- Borosilicate black glass kit
- 8-3/4” deep for framing
- 15,500 BTU
- Non-combustible board
- 45 degree vent off the back of unit
- Basic remote control with receiver – Standing pilot
- Basic remote control – Electronic ignition
- Basic trim & safety barrier (Required)
- Termination kit (Required)
- 3” & 6” Venting
Deluxe System
- True clean face design
- 15,500 BTU
- Electronic ignition
- Borosilicate glass
- 45 degree vent off the back of the unit
- Black reflective fire glass media
- Deluxe digital remote control
- Fan kit
- Modulating valve
IDEAL APPLICATIONS
- New builds & Renovations
- Restaurants
- Commercial Spaces
- Condominiums
GAS SPECIFICATIONS
| Framing Dimensions | Viewing Area | BTUs (NG) | AFUE / P.4 (NG Efficiency) |
Weight* | |
|---|---|---|---|---|---|
| Hi | Low | ||||
|
32-1/2” H x 36” W x 8-3/4” D
|
12” H x 29-1/2” W
|
15,500
|
11,000
|
64.91%
|
90 lbs.
|
|
Venting**
|
Ceiling /
Mantle Height |
|---|---|
|
3” flex vent on exhaust side
6” flex vent on the air intake side |
Internal ceiling = 40”
|
**Venting – Any certified 2 ply flex piping can be used. Certified on Duravent, Selkirk, Metal Fab, ICC
DIMENSION
GLASS VIEWING AREA
- 12” H x 29-1/2” W
OPTIONAL ACCESSORIES
Remote Control for 36" Langley Series Fireplaces
 |
LANG-REMOTE-SP
|
 |
LANG-REMOTE-EI
|
Porcelain liner - Pack of 3
|
LANG-PORC-LINERS
|
Click to see Optional Decorative Media Options
Customize the look of your electric fireplace by purchasing from our selection of stylish decorative media.
|
AMSF‐GLASS‐01 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage
Color: ‘Clear’ |
 |
AMSF‐GLASS‐02 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Light Brown’ |
 |
AMSF‐GLASS‐03 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Charcoal’ |
 |
AMSF‐GLASS‐04 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Champagne’ |
 |
AMSF‐GLASS‐05 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Dark Grey’ |
 |
AMSF‐GLASS‐06 – 1 Box includes approx. 5 lbs of 1″ Clear ‘Gem’ fireglass ‐ 1 sq. ft. of media coverage ‘clear’ Color: ‘Clear’ |
 |
AMSF‐GLASS‐07 – 1 Box includes approx. 5 lbs of white frosted fireglass ‐ 1 sq. ft. of media coverage ‘white’ Color: ‘White’ |
 |
AMSF‐GLASS‐08 – 1 Box includes approx. 5 lbs of dusty purple frosted fireglass ‐ 1 sq. ft. of media coverage ‘white’ Color: ‘Dusty Purple’ |
 |
AMSF‐GLASS‐09 – 1 Box includes approx. 5 lbs of amber small bead fireglass ‐ 1 sq. ft. of media coverage ‘amber’ Color: ‘Amber’ |
 |
AMSF‐GLASS‐10 – 1 Box includes approx. 5 lbs of small bead fireglass ‐ 1 sq. ft. of media coverage ‘orange’ Color: ‘Orange’ |
 |
AMSF‐GLASS‐11 – 1 Box includes approx. 5 lbs of small “suntea’ bead fireglass ‐ 1 sq. ft. of media coverage ‘suntea’ Color: ‘Suntea’ |
 |
AMSF‐GLASS‐12 – 1 Box includes approx. 5 lbs of small “black’ bead fireglass ‐ 1 sq. ft. of media coverage ‘black’ Color: ‘Black’ |
 |
AMSF‐GLASS‐13 – 1 Box includes approx. 5 lbs of small “sable’ bead fireglass ‐ 1 sq. ft. of media coverage ‘sable’ Color: ‘Sable’ |
Click to see Optional Designer Media Kits
|
DESIGN‐MEDIA‐6PCE 6 piece log set with black fire glass, 90 piece pebble, rocks, Embers 1, Embers 2, Embers 3 and Embers 4 Use With:
|
Click to see Fuel Conversion Kit
This conversion kit for the Sierra Flame Langley series direct vent linear fireplace will help you convert your Langley fireplace from one fuel source to another, just select the right one for you.
 |
Fuel Conversion Kit |
Click to see Venting Components
 |
LANG-TERM-KIT"Termination Kit for 3” & 6” Vent. Includes: 1 x wall thimble, Horizontal Term vent & 2’ of Flex"
Note: Langley hard pipe installation requires + LANGTTRK-ADP + DURA-FLEX *Venting Requirements: This unit requires venting pipe with an inner diameter of 3 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit. |
 |
SF94206310 3” X 6” Coaxial Flex, 10’ Length, Langley Horizontal Termination - Not Included Order LANG-TERM-KIT Horizontal Termination W/Fireplace from Sierra Flame to complete kit.
SF42063C Couplers sold separate. |
 |
LANGTTRK-ADP Through the roof adaptor kit Includes 2 adaptors 3" flex to 4" hard & 6" flex to 6-5/8" hard
*Venting Requirements: This unit requires venting pipe with an inner diameter of 3 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit. |
 |
DURA-FLEX Galvanized adaptor to go from flex to hard pipe
*Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit. |
 |
SF942063C 3" x 6" Flex extension coupler kit 1-3" and 1-6"
*Venting Requirements: Langley hard pipe installation requires LANGTTRK-ADP + DURA-FLEX |
DOWNLOADS
